Details

Product code        L009UiGS-2HaxD-IN

Architecture        ARM 64bit

CPU        IPQ-5018

CPU core count        2

CPU nominal frequency        800 MHz

Switch chip model        88E6190

RouterOS license        5

Operating System        RouterOS v7

Size of RAM        512 MB

Storage size        128 MB

Storage type        NAND

MTBF        Approximately 200'000 hours at 25C

Tested ambient temperature        -40°C to 70°C

Suggested price        $129.00

Wireless capabilities

Details

Wireless 2.4 GHz Max data rate        574 Mbit/s

Wireless 2.4 GHz number of chains        2

Wireless 2.4 GHz standards        802.11b/g/n/ax

Antenna gain dBi for 2.4 GHz        4

Wireless 2.4 GHz chip model        IPQ-5018

Wireless 2.4 GHz generation        Wi-Fi 6

WiFi speed        AX600

Ethernet

Details

10/100/1000 Ethernet ports        8

Number of 1G Ethernet ports with PoE-out        1

Fiber

Details

SFP ports        1 (2.5G supported)

Peripherals

Details

Serial console port        RJ45

Number of USB ports        1

USB Power Reset        Yes

USB slot type        USB 3.0 type A

Max USB current (A)        1.5

Powering

Details

Number of DC inputs        2 (DC jack, PoE-IN)

DC jack input Voltage        24-56 V

Max power consumption        42 W

Max power consumption without attachments        14 W

Cooling type        Passive

PoE in        802.3af/at

PoE in input Voltage        24-56 V

PoE-out

Details

PoE-out ports        Ether8

PoE out        Passive PoE

Max out per port output (input 18-30 V)        1 A

Max out per port output (input 30-57 V)        450 mA

Max total out (A)        1.0 A

Certification & Approvals

Details

Certification        CE, FCC, IC, EAC, ROHS

IP        20
