Architecture        MIPSBE

CPU        QCA9533

CPU core count        1

CPU nominal frequency        650 MHz

Dimensions        Wall case: 88 x 52 x 20 mm Ceiling case: ⌀88 mm x 20 mm

RouterOS license        4

Operating System        RouterOS

Size of RAM        64 MB

Storage size        16 MB

Storage type        FLASH

MTBF        Approximately 100'000 hours at 25C

Tested ambient temperature        -40°C to 70°C

Suggested price        $29.00

Wireless capabilities

Details

Wireless 2.4 GHz Max data rate        300 Mbit/s

Wireless 2.4 GHz number of chains        2

Wireless 2.4 GHz standards        802.11b/g/n

Antenna gain dBi for 2.4 GHz        1.5

Wireless 2.4 GHz chip model        QCA9533

Wireless 2.4 GHz generation        Wi-Fi 4

Ethernet

Details

10/100 Ethernet ports        1

Peripherals

Details

Number of USB ports        1

USB slot type        microUSB type AB

Max USB current (A)        1

Powering

Details

MicroUSB input Voltage        5-5 V

Number of DC inputs        2 (PoE-IN, MicroUSB)

Max power consumption        4 W

Cooling type        Passive

PoE in        802.3af/at

PoE in input Voltage        10-60 V

Certification & Approvals

Details

Certification        CE, FCC, IC, EAC, ROHS

IP        IP20

Wireless specifications

2.4 GHz        Transmit (dBm)        Receive Sensitivity

1MBit/s        22        -96

11MBit/s        22        -89

6MBit/s        20        -93

54MBit/s        18        -74

MCS0        20        -93

MCS7        16        -71
