Specifications

Details

Product code        CSS610-8G-2S+IN

Switch chip model        88E6193X

Dimensions        200 x 164 x 44 mm

Operating System        SwitchOS Lite

Storage size        64 KB

Storage type        FLASH

MTBF        Approximately 200'000 hours at 25C

Tested ambient temperature        -20°C to 60°C

Suggested price        $119.00

Powering

Details

Number of DC inputs        2 (DC jack, PoE-IN)

DC jack input Voltage        12-57 V

Max power consumption        11 W

Max power consumption without attachments        5 W

Cooling type        Passive

PoE in        Passive PoE

PoE in input Voltage        12-57 V

Ethernet

Details

10/100/1000 Ethernet ports        8

Fiber

Details

SFP+ ports        2

Certification & Approvals

Details

Certification        CE, EAC, ROHS

IP        IP20
