CPU AR9344

CPU core count 1

CPU nominal frequency 600 MHz

Dimensions 214mm x 86mm for PCB

License level 5

Operating System RouterOS

Size of RAM 128 MB

Storage size 128 MB

Storage type NAND

Tested ambient temperature -40°C to 60°C

Powering

PoE in Passive PoE

PoE in input Voltage 8-30 V

Number of DC inputs 2 (PoE-IN, DC jack)

DC jack input Voltage 8-30 V

Max power consumption 11 W

PoE-out

PoE-out ports Ether10

PoE out Passive PoE

Max out per port output (input < 30 V) 510 mA

Max total out (A) 510 mA

Wireless

Wireless 2.4 GHz Max data rate 300 Mbit/s

Wireless 2.4 GHz number of chains 2

Wireless 2.4 GHz standards 802.11b/g/n

Antenna gain dBi for 2.4 GHz 4

Wireless 2.4 GHz chip model AR9344

Wireless 2.4 GHz generation Wi-Fi 4

Ethernet

10/100 Ethernet ports 5

10/100/1000 Ethernet ports 5

Fiber

SFP DDMI Yes

SFP ports 1

Peripherals

Serial port RJ45

Number of USB ports 1

USB Power Reset Yes

USB slot type USB type A

Max USB current (A)  1

Other

PCB temperature monitor Yes

Voltage Monitor Yes

Certification & Approvals

Certification CE/RED, FCC, IC, EAC, ROHS
